FEV ELECTRONICS CO.,LIMITED
8 Years
| Ask Lasest Price | |
| Brand Name : | FEV |
| Model Number : | NEMA 5-15P |
| Certification : | UL ,CUL CSA |
| Price : | USD 0.5-3.5 /PCS |
| Payment Terms : | T/T, Western Union, MoneyGram |
| Supply Ability : | 1000000 PCS/Month |
| Delivery Time : | 15 Working Days |
Product name : American power supply cords
Item : YY-3J
YY-3J,5-15P America power supply cord plugs with UL CSA certification Rated up to 15A 125V Built to NEMA standard and designed for any 3 prong North America power cord applications,Our America UL CSA power cord products are fully molded with a low profile ergonomic design and RoHS and REACH compliant.
American power supply cords
Applicable cables:
18/3 SJTW/SJTOW/SJTOOW STW/STOW/STOOW SPT-2
SJT/SJTO/SJTOO ST/STO/STOO SPT-3
SJ/SJO/SJOW SW/SOW/SOOW
16/3 SJTW/SJTOW/SJTOOW STW/STOW/STOOW SPT-2
SJT/SJTO/SJTOO ST/STO/STOO SPT-3
SJEW/SJEOW/SJEOOW SEW/SEOW/SEOOW
14/3 SJTW/SJTOW/SJTOOW STW/STOW/STOOW SPT-3
SJT/SJTO/SJTOO ST/STO/STOO
SJ/SJO/SJOW SW/SOW/SOOW
NEMA 5-15P 3 prong USA power cord plug with cUL certification. Rated up to 15A 125V, 13A 125V or 10A 125V. Built to the NEMA 5-15P. Certified cords with RoHS and REACH compliance.
| Connector Standard: | NEMA 5-15P 3P |
| Maximum Current rating: | 15A |
| Maximum Voltage: | 125V |
| Number of Poles and Wires: | 2 poles, 3 wires |
| Available Wire Thickness: | 14 through 18AWG |
| Outer Mold Material: | 35P PVC |
| Blade Material: | Nickel coated Brass |
| Flamability Rating: | UL 94V-0 |
| color: | black is standard but any color available |
| Temperature Rating: | minus 40C though plus 75C and 105C |
| Approvals: | cUL , CSA |
| Environmental Certifications: | RoHS, REACH |
| Testing: | Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity |
| Gauge/ # Conductors | Cord Type | Electrical Rating (Amps/Volts) |
| 18/3 | SJT, SJTW, SJTO, SJTOW (All TPE material), SJT, SJTW, SJTO, SJTOW, EVE, EVJE | 10/125 |
| 16/3 | SJT, SJTW, SJTO, SJTOW (All TPE material), SJT, SJTW, SJTO, SJTOW, EVE, EVJE | 13/125 |
| 14/3 | SJT, SJTW, SJTO, SJTOW (All TPE material), SJT, SJTW, SJTO, SJTOW, EVE, EVJE | 15/125 |
|
|
